Dust Removal Equipment

Name

Medium Frequency Furnace

Remark

Capture Form

Portable Gas Collection

System Airflow (m³/h)

300000

Leakage Rate

≤3%

Filtering Area(m2)

5788

Filtering Wind Speed(m/min)

<1.2

Main Pipe Diameter(mm)

Ф2800X6,

Pipe Flow(m/s)

16-18

Branch Pipe

Ф1600X5,

Exhaust Pipe Diameter(mm)

Ф3400X8 H=20000

Exhaust Flow Velocity (m/s)

11-13

Emission Concentration(mg/Nm³)

≤50

Pulse Valve Caliber

3''

Number of Pulse Valves

120

Bag Specifications

Φ160×6000

Number of Bags

1500

Filter Material

Coated Polyester Needle Felt

<120ºC

Proportion of Filter Material(g/m³)

550

Dust Remover Resistance(Pa)

≤1500

Pulse Valve Blowing Pressure(M Pa)

0.25-0.30
